Endura Hi-Tech Wrap construction ‘HEXA’Hexagonal Belts :

EndurEndura Hi-Tech 'HEXA' V belts are ideally suited for serpentine drives where power needs to be transmitted equally from both sides of the belt. Centrally located cord and special synthetic rubber compounds ensure long V belt life and smooth, capable horsepower capacity.

Feautres

Dual-sided classical profile.

High-strength tensile members.

Engineered rubber compound-impregnated envelope. • Engineered rubber cushion and insulation.

Oil, heat, ozone, and abrasion resistant.

Precise control on construction.

Specialty V Belts:

Request a Call Back

0120 242 1466

Construction Functions
Cover fabric Protects the inner parts of belts and strong abrasion resistance on the pulley groove.
Top cushion rubber Specially designed high modulus top cushionMaintains belt flexibility and to support reverse idler
Tension member Specially designed Tension member is the Primary material for length retention.
Adhesive rubber Specially designed bottom cushion Supports and protects tension member from fraying.
Bottom compression rubber High modulus compression rubber Maintains belt shape& Improves power transmission.

Used on drives having one or more reverse bends and usually where power must be transmitted to or from the belt in both usual and reverse positions.

Length Designation: Le (effective length in mm)
